| Model: 999-8810-000 Specifications |
| 999-8535-000 Specifications |
| Part Numbers |
999-8535-000 (North America), 999-8535-001 (Int'l) |
| Audio Specs |
Frequency Response: 20 HZ to 20KHZ, Dynamic Range: >90dB, THD + Noise: < 0.02% |
| Line Outputs |
Four (4) 3-Pin Balanced, Line Level Outputs |
| AEC Reference Input |
One (1) 3-Pin Balanced, Line Level Input |
| TRIO Mic Ports |
Connectors: Four (4) RJ 45-F, Proprietary Interface with audio, power & control, 100' (30.48m) Cat-5 cable distance |
| Power Supply |
18 VDC, 2.75 Amp, Positive Center |
| Power Consumed |
Maximum of 40 Watts |
| Operating Temp. |
32° to 104° F (0° to 40° C) / 20% to 80% Relative Humidity |
| Dimensions |
8.375" (212.7mm) W x 1.72" (43.7) H x 6.0" (152.4mm) D |
| Weight |
1.45 lbs. (0.657708956434 kg) |
| Warranty |
One year limited warranty on all parts. |
| Model: 999-8860-000 Specifications |
| Part Numbers |
TRIO Ceiling Microphone: 999-8860-000 (White) |
| Audio Specs |
Frequency Response: 20 HZ to 20KHZ, Dynamic Range: >90dB, THD + Noise: < 0.02% |
| Microphones |
Three unidirectional cardioid elements per device, Frequency Response: 100-12kHz, Max Input Level: 115dB/SPL |
| Signal Processing |
Acoustic Echo Cancellation, Noise Reduction, Microphone Gating and Automatic Gain Control |
| TRIO Mic Ports |
Connectors: One(1) RJ 45-F, Proprietary Interface with audio, power and control up to 100' (30.48m) Cat-5 cable distance |
| Quantity |
4 TRIO Ceiling Mic Array |
| Dimensions |
TRIO Ceiling Mic: 2.5" (63.5mm) Diameter Sphere |
| Weight |
TRIO Ceiling Mic: 0.113 lbs. |
| Operating Temp. |
32° to 104° F (0° to 40° C) / 20% to 80% Relative Humidity |
| Power Consumption |
Less than four (4) Watts per mic |
