Model: MX-86 Specifications |
Description |
MX-Series 86-inch interactive flat panel |
Weight |
173 lb. (78.3 kg |
Active touch area |
76 3/8" × 43 3/4" (194.1 cm × 111.2 cm) |
Active image area |
74 5/8" × 42" × (189.5 cm × 106.6 cm) |
Shipping dimensions (including pallet) |
85 1/4" W × 57 3/8" H × 11 5/8" D (216.5 cm× 145.7 cm × 29.5 cm) |
Shipping weight |
240 lb. (109 kg) |
Hardware |
Interaction |
Touch technology |
IR |
Multitouch capabilities |
Up to 10 simultaneous touch, writing or erase points2 |
Object awareness |
Behavior adjusts automatically to the tool or object you’re using, whether it’s a pen, finger or palm. |
Display |
Type |
LED backlit |
Aspect ratio |
16:9 |
Resolution |
4K UHD |
Positioning accuracy |
<2 mm |
Horizontal frequency (minimum) |
31 Hz |
Horizontal frequency (maximum) |
140 kHz |
Vertical frequency (minimum) |
59 Hz |
Vertical frequency (maximum) |
70 Hz |
Contrast ratio (typical) |
1200:1 |
Brightness (maximum) |
≥350 cd/m² |
Refresh frequency |
60 Hz |
Pixel clock (maximum) |
600 MHz |
Pixel dimensions |
0.37 mm |
Viewing angle |
178° |
Response time (typical) |
8 ms |
Ambient light sensor |
Yes |
Audio |
Audio |
10 W integrated speakers (×2) |
Included cables and accessories |
Cables and accessories |
iQ appliance
Country-specific power cable
16' 5" (5 m) USB cable
Wall mount bracket kit
Pen (×2)
Antennas (×2)
IR remote control |
iQ appliance |
Wireless technology |
Bluetooth® dual mode (backwards compatible with Bluetooth 2.1 + EDR) |
Capture options |
Establish a Bluetooth wireless connection with a supported mobile device (see below) by scanning the interactive display’s unique QR code |
Supported languages |
French German Italian Japanese Korean Norwegian Simplified Chinese Spanish Swedish Traditional Chinese |
Mounting holes |
For a standard VESA® 500 mm × 400 mm mounting plate with M6 screws |
Mounting bracket depth |
Minimum clearance depth of 1 1/4" (3 cm) for all components on the back of the interactive display for airflow |
Connectors |
Back |
Connector panel:
HDMI® in (with HDCP 2.2 support) (×2)
VGA in
RJ45 (×2)
USB Type-B (for touch applications) (×1)
USB 2.0 Type-A (×2)
HDMI 1.4 out (HDCP-compliant)34
S/PDIF out (optical)
Stereo 3.5 mm in (for VGA in)
Stereo 3.5 mm out
OPS slot
RS-232 control
iQ appliance (AM40):
USB 3.0 Type-A (×2)
HDMI 1.4 (HDCP-compliant) |
Front |
HDMI in (with HDCP 1.4 support)
USB Type-B (for touch applications)
USB Type-A (×2) |
Applications |
Interactive display |
Apps included in the iQ appliance
One-year subscription to SMARTBOARD Learning Suite |
Storage and operating requirements |
Power requirements |
100V to 240V AC, 50 Hz to 60 Hz |
Standby mode |
≤0.3 W |
Maximum operating |
115 W |
Operating temperature |
41–95°F (5–35°C) |
Storage temperature |
-4–140°F (-20–60°C) |
Humidity |
5–80% relative humidity, non-condensing |
Warranty |
Warranty |
Three-year limited equipment warranty |
Extended warranty |
EWY1-SBID-MX286 |
SBID-MX286 interactive display with iQ one-year warranty extension |
EWY2-SBID-MX286 |
SBID-MX286 interactive display with iQ two-year warranty extension |
