| Panel Technology |
S-IPS |
| Native Resolution |
3840x2160 |
| Pixel Pitch |
0.49 mm |
| Brightness (maximum) |
500 cd/m2 |
| Viewing Angle (typical) |
178° Vert., 178° Hor.
(89U/89D/89L/89R) @ CR>10 |
| Refresh Rate |
60Hz |
| Orientation |
Landscape/Portrait |
| Displayable Colors |
More than 1.07 billion |
| Viewable Image Size |
75" |
| Supported Resolutions |
DisplayPort: V1.2 (HDCP 1.3) VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60, WUXGA60, 1920 x 1080 (60Hz), 1080p, 1080i, 720p@50Hz/60Hz, 576p@50Hz, 480p@60Hz, 3840 x 2160 (24Hz/30Hz/25Hz/60Hz (DisplayPort 1.2)) HDMI: (HDCP 1.4/2.2) VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60, WUXGA60, 1920 x 1080 (60Hz), 1080p, 1080i, 720p@50Hz/60Hz, 576p@50Hz, 480p@60Hz, 576i@50Hz, 480i@60Hz, 3840 x 2160 (24Hz/30Hz/25Hz/60Hz (MODE2)), 4096 x 2160 (30Hz, 24Hz, 25Hz, 60Hz (MODE2)) |
| Pixels Per Inch |
59 PPI |
| Contrast Ratio (typical) |
1300:1 (without local dimming) |
| Response Time (typical) |
8 ms |
| Active Screen Area |
64.95 x 36.53 in. / 1649.66 x 927.94mm |
| Dimming Capability |
Local Dimming Capable |
| Horizontal (Analog/Digital) |
26kHz - 135.0kHz |
| PC Signal Compatibility |
Yes |
| Macintosh Signal Compatibility |
Yes |
| Macintosh Signal Compatibility |
Yes |
| Input Terminals |
| Digital: |
HDMI 2.0 (3), DisplayPort 1.2 (2) |
| Audio: |
Audio Mini-Jack, DisplayPort Audio, HDMI Audio |
| External Control: |
RS-232C, LAN, IR Remote |
| Data: |
microSD (Media Player), USB 2.0 (Media Player, USB (Service), USB Type-B (Upstream), USB x 2 (Both for Compute Module, 1 x 5V/2A Powered) |
| Output Terminals |
| Digital: |
DisplayPort (Outputs DisplayPort1 or Option) |
| Audio: |
Audio Mini-Jack, External Speaker Out (2), DisplayPort Audio |
| External Control: |
LAN |
| On |
155W |
| ECO Mode Standby |
0.5W |
| Network Standby |
2W |
| Power Consumption (max) |
340W (210W Brightness Max) |
| Input Current |
4.0A @ 100V
1.7A @ 240V |
| Bezel Width (Left/Right, Top/Bottom) |
0.58 in./0.58 in., 0.58 in./0.58 in. : 14.8 mm/14.8 mm, 14.8 mm/14.8 mm |
| Dimensions (WxHxD) |
| With stand: |
1681.2 x 996.8 x 606mm / 66.19 x 39.24 x 23.9 in. |
| Without stand: |
66.19 x 37.78 x 2.8 in. / 1681.2 x 959.6 x 71.1 mm |
| Shipping: |
1830.0 x 1190.0 x 280.0mm / 72.05 x 46.85 x 11.02 in. |
| Weight |
| Net Weight (with stand): |
126.1 lbs. / 57.20kg |
| Net Weight (without stand): |
116 lbs. / 52.61 kg. |
| Shipping: |
144.4 lbs. / 65.5kg |
| VESA Hole Configuration |
400 x 400mm (M8 x 16mm)
600 x 400mm (M8 x 16mm) |
| Operating Temperature |
32-104°F / 0-40°C |
| Operating Altitude |
9843 ft. / 3000m |
| Storage Humidity |
10-90% |
| Operating Humidity |
20-80% |
| Storage Temperature |
-4-140°F / -20-60°C |
| Storage Altitude |
40,000 ft. / 12,192m |
| Limited Warranty (parts & labor) |
3 Years Advanced Replacement |
