| Model: W512 Specifications |
| Description |
Professional Installation WXGA Projector |
| Aspect Ratio |
16:10 (native), 16:9, 4:3, LBX and auto compatible |
| Audio |
2 x 10W speakers (stereo) |
| Brightness |
5,500 ANSI lumens |
| Color Wheel |
6 segment RYGCWB |
| Contrast Ratio |
15,000:1 |
| Display Technology |
Single Texas Instruments 0.65″ WXGA DMD |
| Displayable Colors |
1.07 Billion |
| Geometry |
Four corner adjustment |
| Image Size |
25.66" – 301.15" |
| Inputs |
2 x HDMI, 1 x VGA, 1 x composite, 1 x S-Video, 1 x audio (3.5mm) |
| Keystone Correction |
±20° Vertical ±20° Horizontal |
| Light Source Life |
7,000/6,000/5,000/3,000 (Eco+/Dynamic/ECO/Bright) |
| Lens Shift |
Vertical lens shift 16% |
| Light Source |
Lamp (330W) |
| Maximum Resolution |
WUXGA (1920 x 1200) |
| Native Resolution |
WXGA (1280 x 800) |
| Noise Level |
30dB (ECO) |
| Offset |
100% |
| Operating Temperature |
41–104°F (5–40°C), 85% max humidity |
| Outputs |
1 x VGA, 1 x USB (Wi-Fi adapter), 1 x USB (USB display, service), audio out (3.5mm) |
| Power Consumption |
405W typical (Bright), 445W max (Bright), 315W typical (Eco), 347W max (Eco) |
| Power Supply |
AC input 100–240V, 50–60Hz, auto-switching |
| Projection Distance |
2.1’ – 51.5’ (without zoom) |
| Projection Lens |
F=2.5-3.25; F=20.91-32.62mm |
| Projection Method |
Front, rear, ceiling mount, table top |
| Remote Control |
Full size remote with laser |
| Throw Ratio |
1.48 – 2.35 |
| Uniformity |
75% |
| Zoom Type |
1.6x optical, 0.8 – 2.0x digital |
| Compatibility specifications |
| 3D Compatibilty |
Supports all HDMI 1.4a mandatory 3D formats (Frame pack, side-by-side, top-bottom) and up converts frame rate from 60Hz to 120Hz or 24Hz to 144Hz (i.e. 60 or 72 frames per eye). |
| Computer Compatibilty |
VGA, SVGA, HDTV(720P), WXGA, WXGA+, SXGA, SXGA+, UXGA, HDTV(1080p), WUXGA |
| Horizontal Scan Rate |
15.375 – 91.146 KHz |
| Vertical Scan Rate |
24 – 85Hz (120Hz for 3D) |
| Physical specifications |
| Dimensions |
14.17” x 11.61” x 5.34” |
| Security |
Kensington® lock port |
| Weight |
10.2 lbs (4.6 kg) |
| Other |
| Accessories |
AC power cable, remote control, batteries, USB Wi-Fi adapter |
| Optional Accessories |
Lamp, ceiling mount, remote and Wi-Fi adapter |
| UPC |
796435 44 239 2 |
| Warranty Info |
3-year Optoma Express advance exchange warranty, 1-year on lamp |
| Specifications |
| Video Input |
PAL, SECAM, 576i/p, NTSC, 480i/p, HDTV 720p/1080i/1080p |
